Description

Standard design:

Heavy and robust welded construction NC control Nuova Maper HT071 Manual, central cutting gap adjustment via handwheel and scale Motorized backgauge 1000mm with recirculating ball screws and solid guides Backgauge beam can be folded away manually for cutting sheets larger than 1000 mm 1000 mm side stop with scale, T-slot and tilting cam Two front support arms 1000 mm for simplified handling of large sheets Table supports with transfer balls for easier handling of heavy and large sheets Grid as front intervention protection First meter of the finger guard can be folded up to make it easier to insert offcuts LED cutting line lighting with shadow gap via adjustable wire Rear guard via light curtain Single-acting cylinder for cutting, return stroke by means of spring force High-quality blades, suitable for cutting stainless steel Rotating blades, upper blade with two cutting edges and lower blade with four cutting edges Hydraulic and electronic components from renowned manufacturers Special accessories:

Cybelec CybTouch 8 touchscreen NC control unit Motorized cutting gap adjustment Finger guard with light curtain Finger protection with viewing panels Stainless steel support tables Extension of the side stop or the front supports Removable mitre fence 0-180° Laser cutting line indicator Spare blade

• Braced machine bed made of gray cast iron
• Elaborate spindle bearing
